Inclination

• Automatic: -16° to 25° with 0.1° increments
• Manual: 0° to 25° with 5° increments; optional downhill adaptor available down to -25°

Belt Speed

• 1.5 m/min to 102.3 m/min
• Acceleration
• Adjustable 0.0 to 25.5 m/min²

Calibration

• Optional automatic belt speed and odometer distance calibration

Stimulus Options

• Electrical: Up to 2.34 mA, 200 ms pulse, 1-3 times/second
• Air-Puff: Up to 40 PSI, 200 ms pulse, 1-3 times/second
• Acceleration
• Adjustable 0.0 to 25.5 m/min²

Stimulus Repetition Rate

• 1, 2, or 3 Hz

Stimulus Voltage

• 117 VAC, 50/60 Hz

Stimulus Current

• Up to 2.34 mA

Dimensions

• 83.8 x 50.8 x 50.8 cm (33.0” x 20.0” x 20.0”)

Metabolic Only Lanes

• 1-4 individually enclosed per motor controller
• Enclosure Dimensions
